SPECIFICATIONS

Brand Name: TLXT

Brightness: 1000-1500nits
Cabinet Dimension: 240mm*1000mm
Display Function: VIDEO
High-concerned chemical: None
Input Voltage: 110-240V
Installation: fixed
Life span: 100000H
Model Number: P6 P8 P10
Origin: Fulfilled in the USA
Pixels: 6mm
Tube Chip Color: Full Color
is_customized: Yes
use: advertising publish, retail store, shopping mall, welcome display, self-service business, exhibition hall, airport, Restaurant & Hotel Supplies, education






Purchasing Instructions :

The screen size of the unit price is 1000mm*240mm. display playback needs to be used with a video processor (play box).
P6 is the pitch of the lamp beads is 6mm, P8 pitch is 8mm, P10 pitch is 10mm.(We have other models.)
The video processor (player box) has a load pixel of 65W points.
For example: if you need a 1m*1m (one square meter ) LED Transparent Crystal Soft Filmscreen, then you buy pieces and a player box (the actual screen size is 1m*.92m).
If you need to install a larger LED display, you can contact our customer service department to specify a more suitable solution for you.
If your storefront window is exposed to direct sunlight, we have a solution featuring high-brightness LED transparent film screens . These screens, also known as flexible LED transparent displays , are specifically designed for bright environments—unlike standard displays (200-300 nits), they deliver sufficient brightness to remain visible even in broad daylight .Please contact Jacy, and he will send you the detailed solution.
Please contact me to send you a video of the installation.

PRODUCT DESCRIPTION
Specification
Pixel Pitch
P6
P8
P10
Pixel Resolution
166*166/m2
125*125/m2
100*100/m2
Transparency
≥85%
≥85%
≥90%
Brightness
1000-1500cd/m2 (Optional high brightness)
Screen Size (Cabinet Size)
1000mm*240mm
Average Power Consumption
200 W/㎡
